- Microcomputer control - for accuracy and ease of use with a built in temperature memory system in the case of a power failure. Integral over temperature cut off.
- Pure TITANIUM heat exchanger /evaporator - for it's extreme anti corrosion properties in a saltwater environment.
- Low running noise
- High efficiency, latest generation cooler - for low running costs.
- Superior quality condenser - for reliability and low noise.
- Robust metal chassis - for strength and anti vibration properties
- Contemporary housing design - to fit with most decors.
Specifications
- Cooling Power - 2200W
- Voltage - 220-240V
- Frequency - 50Hz
- Current - 3.2A
- Water refrigerated - 1000-2200lts
- Refrigerant - R134a
- Water flow - 1000-2500 lts/hr
- Weight - 31.3Kg
- Hosetail size 25mm (Eheim 25/34mm Hose)
- Dimensions - 520 x 400 x 480mm (Not including hosetail fittings)
- Compressor design - rotary compressor
Performance
The performance chart below shows the cooling curve for the DC2200 working on an aquarium of 1000 litres of water which starts at a water temperature of 28°C. You can see the drop in temperature of the aquarium hour by hour as it is recirculated through the cooler.
The ambient air temperature in the room remains at 30°C throughout the test.
The chart shows that the temperature of the water is reduced by 10°C in a period of 12 hours.
Note that no heat from lighting or other equipment is added to the water mass during the test.
Chiller protected by an external 13amp fused plug, no internal fuse required.
If you need advice on this D&D Aquarium Cooler 1000-2000 litres and whether it's suitable for your aquarium, please contact us and a member of our friendly store team will be more than happy to answer all of your questions.
